PostSubject: New larger Autogyro build.   New larger Autogyro build. EmptyFri 23 Oct 2015, 11:51 am

With the outstanding success of the first autogyro (only joking still trying to fly !) I have commenced building a 1.5 times larger Crane Fly Autogyro.All parts cut by hand from an enlarged plan. The power unit will be a 50 sized four stroke. No more of this electric nonsense.
with a little luck I have posted a picture of the started model.This one will have home made blades and rotor head rotor diameter about one metre...how can it fail you ask!i  There is a carbon fibre boom 900mm long added to this fuss so will make quite a large model.

My new toy also shown.

if there is any interest I will post build pics as they progree.

Happy flying (and crashing as an Autogyro novice)

More build pictures added today.This also shows my first attempt at making blades.The quest is on to fly a autogyro properly(could be a long time).

03/11/15 more pics.Rotors seem massive @ 1.2 metre span. Rotor mast seems too long but is right as per plan ,may reduce its length.Is anyone watching ?
New larger Autogyro build. DSCN0244_zpspeipyv80

New larger Autogyro build. Rotor2_zpsdwukepmq

<a href="https://s1030.photobucket.com/user/drummerboydick/media/DSCN0270_zpsriiqcaec.jpg.html" target="_blank"><img src="https://2img.net/h/i1030.photobucket.com/albums/y369/drummerboydick/DSCN0270_zpsriiqcaec.jpg" border="0" alt=" photo DSCN0270_zpsriiqcaec.jpg"/></a>


New larger Autogyro build. DSCN0243_zpshkqxy4f3


New larger Autogyro build. DSCN0247_zpsq3o2zhua

New larger Autogyro build. DSCN0249_zpsr9pqofoj

New larger Autogyro build. AG%201%201_zpsacunjjeu

New larger Autogyro build. AG2_zpstsvw8yut

New larger Autogyro build. DSCN0250_zps60zlcsuu

New larger Autogyro build. DSCN0248_zpsstb2n1hw

New larger Autogyro build. Rotor1_zpsfadck3g8

Building has progressed it is turning into a monster.Still not sure about rotor mast height it looks too long but is as per the enlarged plan.

New larger Autogyro build. AG3_zps8fcab12u

NEARLY FINISHED.. Here is the latest Contraception nearly done  just mior covering and a small servo issue ..Then Ready for Adrian to try (bring your hard hat)

New larger Autogyro build. DSCN0270_zpsriiqcaec


Last edited by drummerboydick on Sun 20 Dec 2015, 3:23 pm; edited 5 times in total
Back to top Go down
Guest
Guest




New larger Autogyro build. Empty
PostSubject: Re: New larger Autogyro build.   New larger Autogyro build. EmptyFri 23 Oct 2015, 7:17 pm

I for 1 would definitely like to see the build pics .. Bravo
Back to top Go down
Worzey

Worzey


Number of posts : 1298
Age : 51
Location : Ashford
Registration date : 2008-02-09

New larger Autogyro build. Empty
PostSubject: Re: New larger Autogyro build.   New larger Autogyro build. EmptySat 24 Oct 2015, 10:41 am

TheHobman wrote:
I for 1 would definitely like to see the build pics .. Bravo

+1
